Notebook exercise: Sampling methods for EVA

In this interactive notebook you will try two different methods to extract extreme observations from a timesereis.

Click –> Live Code on the top right corner of this screen and then wait until all cells are executed.

Learning objectives: Extract extreme observations using:

• Block Maxima (filter on yearly extremes)

• Peak Over Threshold (Filter values by threshold, chosen with the mean-residual-life method)

Assignment 1: Block Maxima

In this assignment, you will have the following tasks:

1. Extract yearly maxima from the dataset

2. Apply GEV (Generalized Extreme Value) \(\rightarrow\) see MUDE book

3. Determine the return value for a return period of 100 years

import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
from scipy import stats

wavedata = pd.read_csv('data/Wavedata.csv')
display(wavedata.head())

	datetime	Hs
0	01/01/2005 00:00	1.125488
1	01/01/2005 03:00	1.119873
2	01/01/2005 06:00	1.176270
3	01/01/2005 09:00	1.173584
4	01/01/2005 12:00	0.594238

1. Extract yearly maxima from the dataset

annual_max = # YOUR CODE HERE

print(annual_max.head())

  Cell In[4], line 3
    annual_max = # YOUR CODE HERE
                 ^
SyntaxError: invalid syntax

2. Fit the GEV distribution to the selected yearly maxima.

Calculate the 100-year return value for annual maxima with:

\[ \begin{align}\begin{aligned} p = 1 - 1.0/T $$, \\with T = Return Period (years) and:\end{aligned}\end{align} \]

t(x) = \begin{cases} \left[1 + \xi \left(\dfrac{x - \mu}{\sigma}\right)\right]^{1/\xi}, & \xi \neq 0, \[12pt] \exp!\left(\dfrac{x - \mu}{\sigma}\right), & \xi = 0. \end{cases} $$

Hint: use scipy.stats.genextreme.fit() function to extract the relevant parameters of the GEV distribution

c, loc, scale = # YOUR CODE HERE

xi = -c  # shape parameter
mu = loc  # location parameter
sigma = scale  # scale parameter

T = # YOUR CODE HERE
t = # YOUR CODE HERE

print(f'GEV fit parameters:')
print(f'  location μ = {mu:.4f}')
print(f'  scale    σ = {sigma:.4f}')
print(f'  shape    ξ = {xi:.4f}  (note: SciPy returns c = -ξ)\n')
print()
print(f'The GEV value for a return period of {T} years is {t:.4f} m')

  Cell In[10], line 3
    c, loc, scale = # YOUR CODE HERE
                    ^
SyntaxError: invalid syntax

3. Plot the results

plot the pdf of the distribution with a histogram (left) and cdf with empirical points (right)

hint: use scipy.stats.genextreme.pdf() and scipy.stats.genextreme.cdf()

fig, axes = plt.subplots(1, 2, figsize=(11, 4.5), constrained_layout=True)

# Left: histogram + pdf
ax = axes[0]

# YOUR CODE HERE

# Right: empirical cdf + fitted cdf
ax = axes[1]

# YOUR CODE HERE

plt.show()

Assignment 2: Peak-Over-Threshold

In this assignment, you will have the following tasks:

1. Extract maxima from the dataset using a Threshold (\(th = 2.5m\)) and a Declustering Time (\(dl = 48h\))

2. Apply GPD (Generalized Pareto Distribution) \(\rightarrow\) see MUDE book

3. Determine the return value for a return period of 100 years

import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
from scipy import stats

wavedata = pd.read_csv('data/Wavedata.csv')
display(wavedata.head())

	datetime	Hs
0	01/01/2005 00:00	1.125488
1	01/01/2005 03:00	1.119873
2	01/01/2005 06:00	1.176270
3	01/01/2005 09:00	1.173584
4	01/01/2005 12:00	0.594238

1. Extract maxima from the dataset that exceed the Threshold (\(th = 2.5m\)), with a Declustering Time (\(dl = 48h\))

u = 2.5                     # threshold [m]
dl_hours = 48               # declustering window [hours]

exc = # YOUR CODE HERE
if exc.empty:
    raise ValueError("No exceedances found above the threshold.")

clusters = # YOUR CODE HERE
peaks = # YOUR CODE HERE
peaks_times = # YOUR CODE HERE

print(f'Number of exceedance clusters: {len(peaks)}')
print(f'First few peak times and values:\n{pd.Series(peaks.values, index=peak_times.values).head()}\n')

  Cell In[9], line 4
    exc = # YOUR CODE HERE
          ^
SyntaxError: invalid syntax

2. Fit the GPD distribution to the selected maxima.

Calculate the 100-year return value for the selected maxima with:

\[\begin{split} f(x) = \begin{cases} \dfrac{1}{\sigma}\left[1 + \xi\left(\dfrac{x - \mu}{\sigma}\right)\right]^{-1/\xi - 1}, & \xi \neq 0, \\[12pt] \dfrac{1}{\sigma}\exp\!\left(-\dfrac{x - \mu}{\sigma}\right), & \xi = 0. \end{cases} \end{split}\]

Hint: use scipy.stats.genpareto.fit() function to extract the relevant parameters of the GEV distribution

xi, loc, beta = # YOUR CODE HERE

T = # YOUR CODE HERE
t = # YOUR CODE HERE

print('GPD fit parameters (exceedances):')
print(f'  scale  β = {beta:.4f}')
print(f'  shape  ξ = {xi:.4f}')
print(f'  loc    = {loc:.4f} (fixed at 0)\n')
print()
print(f'The GPD value for a return period of {T} years is {t:.4f} m')

  Cell In[12], line 1
    xi, loc, beta = # YOUR CODE HERE
                    ^
SyntaxError: invalid syntax

3. Plot the results

plot the pdf of the distribution with a histogram (left) and cdf with empirical points (right)

hint: use scipy.stats.genpareto.pdf() and scipy.stats.genpareto.cdf()

fig, axes = plt.subplots(1, 2, figsize=(11, 4.5), constrained_layout=True)

# Left: histogram + pdf
ax = axes[0]

# YOUR CODE HERE

# Right: empirical cdf + fitted cdf
ax = axes[1]

# YOUR CODE HERE

plt.show()
